Pectus carinatum (peito de pombo) Ir para: navegação, pesquisa

Clinically Relevant Anatomy

Pectus carinatum is a term used to describe a spectrum of protrusion abnormalities of the anterior chest wall. The deformity may be classified as either chondrogladiolar or chondromanubrial, depending on the site of greatest prominence.^[2] Lateral deformities are also possible.

Hippocrates described the carinatum deformity as a “sharply pointed chest” and reported that patients became “affected with difficulty breathing.” Symptomatic patients report dyspnea and decreased endurance. Some develop rigidity of the chest wall with decreased lung compliance, progressive emphysema, and increased frequency of respiratory tract infections. Many affected patients have no physical complaints; however, concerns about body image have been associated with low self-esteem and a decreased mental quality of life. Cosmetic concerns can be significant factors in opting for correction.Barrel chest deformities with increased anteroposterior (AP) chest diameters can be seen in obstructive forms of chronic pulmonary disease, such as cystic fibrosis and untreated or poorly controlled asthma.^[2]

Pathology

Pectus carinatum is an overgrowth of costal cartilage causing the sternum to protrude forward. It primarily occurs among four different patient groups, and males are more frequently affected than females. Most commonly, pectus carinatum develops in 11-to-14-year-old pubertal males undergoing a growth spurt^[2]. Some parents report that their child’s pectus carinatum seemingly popped up overnight. Second most common is the presence of pectus carinatum at or shortly after birth. The condition may be evident in newborns as a rounded anterior chest wall. As the child reaches age 2 or 3 years of age, the outward sternal protrusion becomes more pronounced. Pectus carinatum can also be caused by vitamin D deficiency in children (Rickets) due to deposition of unmineralized osteoid. Least common is a pectus carinatum deformity following open-heart surgery or in children with poorly controlled bronchial asthma.

Pectus carinatum is generally a solitary, non-syndromic abnormality. However, the condition may be present in association with other syndromes: Turner syndrome, Noonan syndrome, Loeys-Dietz syndrome, Marfan syndrome, Ehlers-Danlos syndrome, Morquio syndrome, trisomy 18, trisomy 21, homocystinuria, osteogenesis imperfecta, multiple lentigines syndrome (LEOPARD syndrome), Sly syndrome (mucopolysaccharidosis type VII), and scoliosis.^[2]

In about 25% of cases of pectus carinatum, the patient has a family member with the condition.

Clinical Presentation

People with pectus carinatum usually develop normal hearts and lungs, but the deformity may prevent these from functioning optimally. In moderate to severe cases of pectus carinatum, the chest wall is rigidly held in an outward position.^[3] Thus, respirations are inefficient and the individual needs to use the accessory muscles for respiration, rather than normal chest muscles, during strenuous exercise. This negatively affects gas exchange and causes a decrease in stamina. Children with pectus deformities often tire sooner than their peers, due to shortness of breath and fatigue. Commonly concurrent is mild to moderate asthma.^[2][3]

Some children with pectus carinatum also have scoliosis (i.e., curvature of the spine). Some have mitral valve prolapse, a condition in which the heart mitral valve functions abnormally. Connective tissue disorders involving structural abnormalities of the major blood vessels and heart valves are also seen. Although rarely seen, some children have other connective tissue disorders, including arthritis, visual impairment and healing impairment.

Apart from the possible physiologic consequences, pectus deformities can have a significant psychologic impact. Some people, especially those with milder cases, live happily with pectus carinatum. For others, though, the shape of the chest can damage their self-image and confidence, possibly disrupting social connections and causing them to feel uncomfortable throughout adolescence and adulthood. As the child grows older, bodybuilding techniques may be useful for balancing visual impact.

A less common variant of pectus carinatum is pectus arcuatum (also called type 2 pectus excavatum, chondromanubrial deformity or Currarino–Silverman syndrome or pouter pigeon deformity), which produces a manubrial and upper sternal protrusion, particularly also at the sternal angle.^[2] Pectus arcuatum is often confused with a combination of pectus carinatum and pectus excavatum, but in pectus arcuatum the visual appearance is characterized by a protrusion of the costal cartilages and there is no depression of the sternum.

Causes

Pectus carinatum is an overgrowth of costal cartilage causing the sternum to protrude forward. It primarily occurs among four different patient groups, and males are more frequently affected than females. Most commonly, pectus carinatum develops in 11-to-14-year-old pubertal males undergoing a growth spurt.^[3] Some parents report that their child’s pectus carinatum seemingly popped up overnight. Second most common is the presence of pectus carinatum at or shortly after birth. The condition may be evident in newborns as a rounded anterior chest wall. As the child reaches age 2 or 3 years of age, the outward sternal protrusion becomes more pronounced. Pectus carinatum can also be caused by vitamin D deficiency in children (Rickets) due to deposition of unmineralized osteoid. Least common is a pectus carinatum deformity following open-heart surgery or in children with poorly controlled bronchial asthma.

Pectus carinatum is generally a solitary, non-syndromic abnormality. However, the condition may be present in association with other syndromes: Turner syndrome, Noonan syndrome, Loeys-Dietz syndrome, Marfan syndrome, Ehlers-Danlos syndrome, Morquio syndrome, trisomy 18, trisomy 21, homocystinuria, osteogenesis imperfecta, multiple lentigines syndrome (LEOPARD syndrome), Sly syndrome (mucopolysaccharidosis type VII), and scoliosis.

In about 25% of cases of pectus carinatum, the patient has a family member with the condition.

Diagnostic Procedures

Pectus deformities usually become more severe during adolescent growth years and may worsen throughout adult life. The secondary effects, such as scoliosis and cardiovascular and pulmonary conditions, may worsen with advancing age.

Body building exercises (often attempted to cover the defect with pectoral muscles) will not alter the ribs and cartilage of the chest wall, and are generally considered not harmful.

Most insurance companies no longer consider chest wall deformities like pectus carinatum to be purely cosmetic conditions. While the psychologic impact of any deformity is real and must be addressed, the physiological concerns must take precedence. The possibility of lifelong cardiopulmonary difficulties is serious enough to warrant a visit to a thoracic surgeon.

Management / Interventions

External bracing technique

External brace for treatment of Pectus Carinatum^[4]

The use of orthotic bracing, pioneered by Sydney Haje as of 1977, is finding increasing acceptance as an alternative to surgery in select cases of pectus carinatum.^[5] In children, teenagers, and young adults who have pectus carinatum and are motivated to avoid surgery, the use of a customized chest-wall brace that applies direct pressure on the protruding area of the chest produces excellent outcomes. Willingness to wear the brace as required is essential for the success of this treatment approach. The brace works in much the same way as orthodontics (braces that correct the alignment of teeth). The brace consists of front and back compression plates that are anchored to aluminum bars. These bars are bound together by a tightening mechanism which varies from brace to brace. This device is easily hidden under clothing and must be worn from 14 to 24 hours a day. The wearing time varies with each brace manufacturer and the managing physicians protocol, which could be based on the severity of the carinatum deformity (mild moderate severe) and if it is symmetric or asymmetric.^[6]

Depending on the manufacturer and/or the patient’s preference, the brace may be worn on the skin or it may be worn over a body ‘sock’ or sleeve called a Bracemate, specifically designed to be worn under braces. A physician or orthotist or brace manufacturer’s representative can show how to check to see if the brace is in correct position on the chest.^[5]

Bracing is becoming more popular over surgery for pectus carinatum, mostly because it eliminates the risks that accompany surgery.^[7] The prescribing of bracing as a treatment for pectus carinatum has ‘trickled down’ from both paediatric and thoracic surgeons to the family physician and pediatricians again due to its lower risks and well-documented very high success results. The pectus carinatum guideline of 2012 of the American Pediatric Surgical Association has stated: “As reconstructive therapy for the compliant pectus [carinatum] deformity, nonoperative compressive orthotic bracing is usually an appropriate first line of therapy as it does not preclude the operative option. For appropriate candidates, orthotic bracing of chest wall deformities can reasonably be expected to prevent worsening of the deformity and often results in a lasting correction of the deformity. Orthotic bracing is often successful in prepubertal children whose chest wall is compliant. Expert opinion suggests that the noncompliant chest wall deformity or significant asymmetry of the pectus carinatum deformity caused by a concomitant excavatum-type deformity may not respond to orthotic bracing.”^[5]

Regular supervision during the bracing period is required for optimal results. Adjustments may be needed to the brace as the child grows and the pectus improves.

Surgical

For patients with severe pectus carinatum, surgery may be necessary. However bracing could and may still be the first line of treatment. Some severe cases treated with bracing may result in just enough improvement that patient is happy with the outcome and may not want surgery afterwards.^[8]

If bracing should fail for whatever reason then surgery would be the next step. The two most common procedures are the Ravitch technique and the Reverse Nuss procedure.^[9]

A modified Ravitch technique uses bioabsorbable material and postoperative bracing, and in some cases a diced rib cartilage graft technique.

The Nuss was developed by Donald Nuss at the Children’s Hospital of the King’s Daughters in Norfolk, Va. The Nuss is primarily used for Pectus Excavatum, but has recently been revised for use in some cases of PC, primarily when the deformity is symmetrical.^[10][11]

^[12]

Other options

After adolescence, some men and women use bodybuilding as a means to hide their deformity. Some women find that their breasts, if large enough, serve the same purpose. Some plastic surgeons perform breast augmentation to disguise mild to moderate cases in women. Bodybuilding is suggested for people with symmetrical pectus carinatum.

References

1. ↑ Shamberger RC, Welch KJ. Surgical correction of pectus carinatum. Journal of pediatric surgery. 1987 Jan 1;22(1):48-53.
2. ↑ ^{2.02.12.22.32.42.5} Croitoru D, Nuss D. Chest wall anomalies: pectus excavatum and pectus carinatum. Adolesc Med. 2004;15:455-71.
3. ↑ ^3.03.13.2 Shamberger RC. Congenital chest wall deformities. Current problems in surgery. 1996 Jun 1;33(6):469-542.
4. ↑ Shamberger RC, Welch KJ. Surgical correction of pectus carinatum. Journal of pediatric surgery. 1987 Jan 1;22(1):48-53.
5. ↑ ^5.05.15.2 Frey AS, Garcia VF, Brown RL, Inge TH, Ryckman FC, Cohen AP, Durrett G, Azizkhan RG. Nonoperative management of pectus carinatum. Journal of pediatric surgery. 2006 Jan 1;41(1):40-5.
6. ↑ Kravarusic D, Dicken BJ, Dewar R, Harder J, Poncet P, Schneider M, Sigalet DL. The Calgary protocol for bracing of pectus carinatum: a preliminary report. Journal of pediatric surgery. 2006 May 1;41(5):923-6.
7. ↑ Lee SY, Lee SJ, Jeon CW, Lee CS, Lee KR. Effect of the compressive brace in pectus carinatum. European Journal of Cardio-Thoracic Surgery. 2008 Jul 1;34(1):146-9.
8. ↑ Robicsek F, Watts LT, Fokin AA. Surgical repair of pectus excavatum and carinatum. InSeminars in thoracic and cardiovascular surgery 2009 Mar 1 (Vol. 21, No. 1, pp. 64-75). WB Saunders.
9. ↑ Shamberger RC, Welch KJ. Surgical correction of pectus carinatum. Journal of pediatric surgery. 1987 Jan 1;22(1):48-53.
10. ↑ Fonkalsrud EW, Beanes S. Surgical management of pectus carinatom: 30 years’ experience. World journal of surgery. 2001 Jul 1;25(7):898-903.
11. ↑ Sigalet DL, Montgomery M, Harder J, Wong V, Kravarusic D, Alassiri A. Long term cardiopulmonary effects of closed repair of pectus excavatum. Pediatric surgery international. 2007 May 1;23(5):493-7.
12. ↑
